GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 114 of 123
7060 Mains failure voltage
No. Setting Min. setting Max. setting Factory
setting
7063* Mains failure U low Set point 80 % 100 % 92 %
7061* Mains failure Timer 1.0 s 990.0 s 5.0 s
7064* Mains failure U high Set point 100 % 120 % 103 %
7062 Mains OK voltage
No. Setting Min. setting Max. setting Factory
setting
7062* Mains OK U Timer 1.0 s 9900.0 s 60.0 s
7065 Mains failure control
No. Setting Min. setting Max. setting Factory
setting
7065 Mains failure control Start eng. +
open MB
Start eng. Start eng. +
open MB
7070 Mains failure frequency
No. Setting Min. setting Max. setting Factory
setting
7073 Mains failure f low* Set point 80 % 100 % 97 %
7071 Mains failure* Timer 1.0 s 990.0 s 5.0 s
7074 Mains failure f high* Set point 100 % 120 % 103 %
7072 Mains OK frequency
No. Setting Min. setting Max. setting Factory
setting
7072 Mains OK f* Timer 1.0 s 9900.0 s 60.0 s
7080 MB close delay
No. Setting Min. setting Max. setting Factory
setting
7082 MB close delay Timer 0.0 s 30.0 s 0.5 s
7083 MB pulse ON time
No. Setting Min. setting Max. setting Factory
setting
7084 MB pulse ON time Timer 0.1 s 10.0 s 0.5 s
7090 Island test function
No. Setting Min.
setting
Second
setting
Max.
setting
Factory
setting
7091 Activation Set point Digital input Button Digital input
or button
Button
7092 Timer Timer 0.0 s - 3200.0 s 30.0 s
7093 Enable Enable OFF - ON ON
7110 Mains failure voltage unbalance
No. Setting Min. setting Max. setting Factory
setting
7110 Mains failure unbalance Enable OFF ON OFF
7111 Mains unbalance failure Timer 1.0 s 990.0 s 5.0 s
7112 Mains unbalance OK Timer 10.0 s 990.0 s 60.0 s
7114 Mains unbalance volt. Set point 0 % 50 % 5 %
