Deif GC-1F Installation Instructions

GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 63 of 123
Analogue inputs 0(4) to 20 mA
The 0(4) to 20 mA setting can only be set in the PC utility software.
4 to 20 mA inputs have wire break detection; the detection limit is 2.5 mA.
Settings:
Scale top point value (click the ‘...’).
Alarm set point: Freely configurable (click the ‘...’).
Scale low point value.
Tick boxes: Select the needed function.
Unit: For example Bar, F, C, PSI.
