Deif GC-1F Installation Instructions

GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 102 of 123
Analogue inputs 0(4) to 20 mA
The scaling of the 0(4) to 20 mA inputs for correct display reading can only be done via the PC
utility software.
4120 0-20 4-20 mA 1.1
No. Setting Min. setting Max. setting Factory
setting
4121 0(4)-20 mA 1.1 Set point 4 mA 20 mA 10 mA
4122 0(4)-20 mA 1.1 Delay 0.0 s 100.0 s 5.0 s
4123 0(4)-20 mA 1.1 Output A R0 (none) R26 (relay 26) R0 (none)
4124 0(4)-20 mA 1.1 Output B R0 (none) R26 (relay 26) R0 (none)
4125 0(4)-20 mA 1.1 Enable OFF ON OFF
4126 0(4)-20 mA 1.1 Fail class See description of fail classes
4130 0-20 4-20 mA 1.2
No. Setting Min. setting Max. setting Factory
setting
4131 0(4)-20 mA 1.2 Set point 4 mA 20 mA 10 mA
4132 0(4)-20 mA 1.2 Delay 0.0 s 100.0 s 5.0 s
4133 0(4)-20 mA 1.2 Output A R0 (none) R26 (relay 26) R0 (none)
4134 0(4)-20 mA 1.2 Output B R0 (none) R26 (relay 26) R0 (none)
4135 0(4)-20 mA 1.2 Enable OFF ON OFF
4136 0(4)-20 mA 1.2 Fail class See description of fail classes
4250 0-20 4-20 mA 2.1
No. Setting Min. setting Max. setting Factory
setting
4251 0(4)-20 mA 2.1 Set point 4 mA 20 mA 10 mA
4252 0(4)-20 mA 2.1 Delay 0.0 s 100.0 s 5.0 s
4253 0(4)-20 mA 2.1 Output A R0 (none) R26 (relay 26) R0 (none)
4254 0(4)-20 mA 2.1 Output B R0 (none) R26 (relay 26) R0 (none)
4255 0(4)-20 mA 2.1 Enable OFF ON OFF
4256 0(4)-20 mA 2.1 Fail class See description of fail classes
4260 0-20 4-20 mA 2.2
No. Setting Min. setting Max. setting Factory
setting
4261 0(4)-20 mA 2.2 Set point 4 mA 20 mA 10 mA
4262 0(4)-20 mA 2.2 Delay 0.0 s 100.0 s 5.0 s
4263 0(4)-20 mA 2.2 Output A R0 (none) R26 (relay 26) R0 (none)
4264 0(4)-20 mA 2.2 Output B R0 (none) R26 (relay 26) R0 (none)
4265 0(4)-20 mA 2.2 Enable OFF ON OFF
4266 0(4)-20 mA 2.2 Fail class See description of fail classes
4380 0-20 4-20 mA 3.1
No. Setting Min. setting Max. setting Factory
setting
4381 0(4)-20 mA 3.1 Set point 4 mA 20 mA 10 mA
4382 0(4)-20 mA 3.1 Delay 0.0 s 100.0 s 5.0 s
4383 0(4)-20 mA 3.1 Output A R0 (none) R26 (relay 26) R0 (none)
4384 0(4)-20 mA 3.1 Output B R0 (none) R26 (relay 26) R0 (none)
4385 0(4)-20 mA 3.1 Enable OFF ON OFF
4386 0(4)-20 mA 3.1 Fail class See description of fail classes
4 to 20 mA inputs have wire break function. Wire break alarm will be active when
current goes below 2.5 mA. It is not possible to disable the wire break function.
