7. Parameter list
This chapter includes a complete standard parameter list for setup. Therefore, this chapter is to
be used for reference when information about specific parameters is needed.
Parameter groups
In the parameter overview, the parameters are divided into three parameter groups. The
parameter groups can be enabled and disabled in the parameters 6950 to 6970. If a parameter
group is enabled, the parameters will be accessible from the display of the GC-1F. To see the
specific parameter, refer to the parameter list. If for example a parameter is marked (P2), it is
available from the display, if parameter group 2 is enabled. The default display parameter setting
is the parameter setting that will always be present in the display parameter list. These
parameters are marked with a *.
Setup
The setup of parameters is performed via the display or the PC utility software (USW).
Therefore, the default settings can be changed to the relevant settings through the utility
software or by means of the push-buttons on the display.
The settings can be entered through the setup menu. If no entry has taken place before, then
the first display to appear is the password display. Enter the factory setting password to gain
access to the menus.
If no action has been taken after 30 seconds, then the password entry will be deactivated, and a
new password entry is needed. (If entry via the USW is used, the password is only needed once
per connection).
Each parameter description is structured according to the same principles. Under the parameter
title heading, the detailed parameter descriptions are illustrated and presented. First, a table
indicating the parameter facts related to the individual parameter title is presented:
4310 VDO input – oil pressure 2.x
No. Setting Min. setting Max. setting Factory
setting
4311 Oil pressure 2.1 Set point 0.0 bar 10.0 bar 4.0 bar
4312 Oil pressure 2.1 Delay 0.0 s 100.0 s 5.0 s
4313 Oil pressure 2.1 Output A R0 (none) R26 (relay 26) R0 (none)
4314 Oil pressure 2.1 Output B R0 (none) R26 (relay 26) R0 (none)
4315 Oil pressure 2.1 Enable OFF ON OFF
4316 Oil pressure 2.1 Fail class Warning Shutdown Trip of GB
Changeable
settings
Min. - max. set
points
Default set point
from factory
Channel
number
indicated in
USW
Para-
meter
title
The factory customer password is 2000. The factory service password is 2001.
