DEIF A/S Page 105 of 123
4560 Hz/V failure
No. Setting Min. setting Max. setting Factory
setting
4561 Hz/V failure* Timer 1.0 s 99.0 s 30.0 s
4562 Hz/V failure Relay output A R0 (none) R26 (relay 26) R0 (none)
4563 Hz/V failure Relay output B R0 (none) R26 (relay 26) R0 (none)
4565 Hz/V failure Enable OFF ON ON
4566 Hz/V failure Fail class See description of fail classes
When the frequency and voltage have not been OK for the adjusted delay time, a Hz/V failure
alarm occurs, and output A and B activate.
4580 Stop failure
No. Setting Min. setting Max. setting Factory
setting
4581 Stop failure* Timer 10.0 s 120.0 s 30.0 s
4582 Stop failure Relay output A R0 (none) R26 (relay 26) R0 (none)
4583 Stop failure Relay output B R0 (none) R26 (relay 26) R0 (none)
4584 Stop failure Enable ON OFF ON
4585 Stop failure Fail class See description of fail classes
If the engine has not stopped within the delay time, outputs A and B will activate and a stop
failure alarm occurs.
4600 V-belt/RPM input failure
No. Setting Min. setting Max. setting Factory
setting
4601 V-belt (P3) Timer 0.0 s 10.0 s 1.0 s
4602 V-belt Relay output A R0 (none) R26 (relay 26) R0 (none)
4603 V-belt Relay output B R0 (none) R26 (relay 26) R0 (none)
4604 V-belt Enable OFF ON OFF
4605 V-belt Fail class See description of fail classes
4610 Charger gen.
No. Setting Min. setting Max. setting Factory
setting
4611 Charger gen. (P3) Timer 0.0 s 60.0 s 0.2 s
4612 Charger gen. Relay output A R0 (none) R26 (relay 26) R0 (none)
4613 Charger gen. Relay output B R0 (none) R26 (relay 26) R0 (none)
4614 Charger gen. Enable OFF ON OFF
4615 Charger gen. Fail class See description of fail classes
The V-belt failure is used on air-cooled engines to monitor that the V-belt driven
cooling fan is operating properly. This alarm requires W input to be used in
parallel with another running feedback at the same time. The status of both will
be compared. If they do not match, a V-belt alarm will be activated.
This alarm requires D+ input to be used in parallel with another running
feedback at the same time (binary input, tacho, generator voltage). The status of
both will be compared. If they do not match, a charger gen. alarm will be
activated.
