Deif GC-1F Installation Instructions

GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 94 of 123
1150 Gen over-voltage
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1151 Over-voltage (P2) Set point 80.0 % 150.0 % - 115.0 %
1152 Over-voltage (P2) Timer 0.1 s 100.0 s - 10.0 s
1153 Over-voltage Relay output A R0 (none) R26 (relay 26) - R0 (none)
1154 Over-voltage Relay output B R0 (none) R26 (relay 26) - R0 (none)
1155 Over-voltage Enable OFF ON Inhibit ON
1156 Over-voltage Fail class Warning Shutdown - Warning
1160 Gen over-voltage 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1161 Over-voltage2(P2) Set point 80.0 % 120.0 % - 117.0 %
1162 Over-voltage2(P2) Timer 0.1 s 100.0 s - 10.0 s
1163 Over-voltage2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1164 Over-voltage2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1165 Over-voltage2 Enable OFF ON Inhibits ON
1166 Over-voltage2 Fail class Warning Shutdown - Warning
1170 Gen under-voltage
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1171 Under-voltage (P2) Set point 50.0 % 110.0 % - 90.0 %
1172 Under-voltage (P2) Timer 0.1 s 100.0 s - 5.0 s
1173 Under-voltage Relay output A R0 (none) R26 (relay 26) - R0 (none)
1174 Under-voltage Relay output B R0 (none) R26 (relay 26) - R0 (none)
1175 Under-voltage Enable OFF ON Inhibit ON
1176 Under-voltage Fail class Warning Shutdown - Warning
1180 Gen under-voltage 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1171 Under-voltage2(P2) Set point 50.0 % 110.0 % - 85.0 %
1172 Under-voltage2(P2) Timer 0.1 s 100.0 s - 5.0 s
1173 Under-voltage2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1174 Under-voltage2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1175 Under-voltage2 Enable OFF ON Inhibits ON
1176 Under-voltage2 Fail class Warning Shutdown - Warning
1210 Gen over-frequency
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1211 Over-frequency (P2) Set point 80.0 % 150.0 % - 115.0 %
1212 Over-frequency (P2) Timer 0.1 s 100.0 s - 10.0 s
1213 Over-frequency Relay output A R0 (none) R26 (relay 26) - R0 (none)
1214 Over-frequency Relay output B R0 (none) R26 (relay 26) - R0 (none)
1215 Over-frequency Enable OFF ON Inhibit ON
1216 Over-frequency Fail class Warning Shutdown - Warning
