GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 95 of 123
1220 Gen over-frequency 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1221 Over-frequency 2 Set point 80.0 % 120.0 % - 117.0 %
1222 Over-frequency 2 Timer 0.1 s 100.0 s - 10.0 s
1223 Over-frequency 2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1224 Over-frequency 2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1225 Over-frequency 2 Enable OFF ON Inhibits ON
1226 Over-frequency 2 Fail class Warning Shutdown - Warning
1240 Gen under-frequency
No. Setting Min.
setting
Max. setting Third
setting
Factory
setting
1241 Under-frequency (P2) Set point 50.0 % 110.0 % - 90.0 %
1242 Under-frequency (P2) Timer 0.1 s 100.0 s - 5.0 s
1243 Under-frequency Relay output A R0 (none) R26 (relay 26) - R0 (none)
1244 Under-frequency Relay output B R0 (none) R26 (relay 26) - R0 (none)
1245 Under-frequency Enable OFF ON Inhibit ON
1246 Under-frequency Fail class Warning Shutdown - Warning
1250 Gen under-frequency 2
No. Setting Min.
setting
Max. setting Third
setting
Factory
setting
1251 Under-frequency 2 (P2) Set point 50.0 % 110.0 % - 85.0 %
1252 Under-frequency 2 (P2) Timer 0.1 s 100.0 s - 5.0 s
1253 Under-frequency 2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1254 Under-frequency 2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1255 Under-frequency 2 Enable OFF ON Inhibits ON
1256 Under-frequency 2 Fail class Warning Shutdown - Warning
1270 Busbar over-voltage
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1151 Over-voltage Set point 80.0 % 150.0 % - 115.0 %
1152 Over-voltage Timer 0.1 s 100.0 s - 10.0 s
1153 Over-voltage Relay output A R0 (none) R26 (relay 26) - R0 (none)
1154 Over-voltage Relay output B R0 (none) R26 (relay 26) - R0 (none)
1155 Over-voltage Enable OFF ON Inhibit ON
1156 Over-voltage Fail class Warning Shutdown - Warning
1280 Busbar over-voltage 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1161 Over-voltage2 Set point 80.0 % 120.0 % - 117.0 %
1162 Over-voltage2 Timer 0.1 s 100.0 s - 10.0 s
1163 Over-voltage2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1164 Over-voltage2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1165 Over-voltage2 Enable OFF ON Inhibits ON
1166 Over-voltage2 Fail class Warning Shutdown - Warning
Busbar protections are only available in HW 1.05 and SW 2.x.x
