Deif GC-1F Installation Instructions

GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 96 of 123
1300 Busbar under-voltage
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1171 Under-voltage Set point 50.0 % 110.0 % - 90.0 %
1172 Under-voltage Timer 0.1 s 100.0 s - 5.0 s
1173 Under-voltage Relay output A R0 (none) R26 (relay 26) - R0 (none)
1174 Under-voltage Relay output B R0 (none) R26 (relay 26) - R0 (none)
1175 Under-voltage Enable OFF ON Inhibit ON
1176 Under-voltage Fail class Warning Shutdown - Warning
1310 Busbar under-voltage 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1171 Under-voltage2 Set point 50.0 % 110.0 % - 85.0 %
1172 Under-voltage2 Timer 0.1 s 100.0 s - 5.0 s
1173 Under-voltage2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1174 Under-voltage2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1175 Under-voltage2 Enable OFF ON Inhibits ON
1176 Under-voltage2 Fail class Warning Shutdown - Warning
1350 Busbar over-frequency
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1211 Over-frequency Set point 80.0 % 150.0 % - 115.0 %
1212 Over-frequency Timer 0.1 s 100.0 s - 10.0 s
1213 Over-frequency Relay output A R0 (none) R26 (relay 26) - R0 (none)
1214 Over-frequency Relay output B R0 (none) R26 (relay 26) - R0 (none)
1215 Over-frequency Enable OFF ON Inhibit ON
1216 Over-frequency Fail class Warning Shutdown - Warning
1360 Busbar over-frequency 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1221 Over-frequency 2 Set point 80.0 % 120.0 % - 117.0 %
1222 Over-frequency 2 Timer 0.1 s 100.0 s - 10.0 s
1223 Over-frequency 2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1224 Over-frequency 2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1225 Over-frequency 2 Enable OFF ON Inhibits ON
1226 Over-frequency 2 Fail class Warning Shutdown - Warning
1380 Busbar under-frequency
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1241 Under-frequency Set point 50.0 % 110.0 % - 90.0 %
1242 Under-frequency Timer 0.1 s 100.0 s - 5.0 s
1243 Under-frequency Relay output A R0 (none) R26 (relay 26) - R0 (none)
1244 Under-frequency Relay output B R0 (none) R26 (relay 26) - R0 (none)
1245 Under-frequency Enable OFF ON Inhibit ON
1246 Under-frequency Fail class Warning Shutdown - Warning
