DEIF A/S Page 97 of 123
1390 Busbar under-frequency 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1251 Under-frequency 2 Set point 50.0 % 110.0 % - 85.0 %
1252 Under-frequency 2 Timer 0.1 s 100.0 s - 5.0 s
1253 Under-frequency 2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1254 Under-frequency 2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1255 Under-frequency 2 Enable OFF ON Inhibits ON
1256 Under-frequency 2 Fail class Warning Shutdown - Warning
1450 Gen overload 1
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1451 Overload 1(P2) Set point 10.0 % 200.0 % - 100.0 %
1452 Overload 1(P2) Timer 0.1 s 3200.0 s - 5.0 s
1453 Overload 1 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1454 Overload 1 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1455 Overload 1 Enable OFF ON Inhibits ON
1456 Overload 1 Fail class Warning Shutdown - Warning
1460 Gen overload 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1461 Overload 2(P2) Set point 10.0 % 200.0 % - 110.0 %
1462 Overload 2(P2) Timer 0.1 s 3200.0 s - 5.0 s
1463 Overload 2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1464 Overload 2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1465 Overload 2 Enable OFF ON Inhibits ON
1466 Overload 2 Fail class Warning Shutdown - Warning
1520 Gen –Q>
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1521 –Q> (P2) Set point 0.0 % 150.0 % - 50.0 %
1522 –Q> (P2) Timer 0.1 s 100.0 s - 10.0 s
1523 –Q> Relay output A R0 (none) R26 (relay 26) - R0 (none)
1524 –Q> Relay output B R0 (none) R26 (relay 26) - R0 (none)
1525 –Q> Enable OFF ON Inhibits OFF
1526 –Q> Auto
acknowledge
OFF ON OFF
1527 –Q> Fail class Warning Shutdown - Warning
1530 Gen Q>
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1531 Q> (P2) Set point 0.0 % 150.0 % - 50.0 %
1532 Q> (P2) Timer 0.1 s 100.0 s - 10.0 s
1533 Q> Relay output A R0 (none) R26 (relay 26) - R0 (none)
1534 Q> Relay output B R0 (none) R26 (relay 26) - R0 (none)
1535 Q> Enable OFF ON Inhibits OFF
1536 Q> Auto
acknowledge
OFF ON OFF
1537 Q> Fail class Warning Shutdown - Warning
