Deif GC-1F Installation Instructions

GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 98 of 123
1620 Mains voltage unbalance
No. Setting Min. setting Max. setting Factory
setting
1621 Voltage unbalance Set point 0.0 % 50.0 % 10.0 %
1622 Voltage unbalance Timer 0.0 s 10.0 s 1.0 s
1623 Voltage unbalance Relay output A R0 (none) R26 (relay 26) R0 (none)
1624 Voltage unbalance Relay output B R0 (none) R26 (relay 26) R0 (none)
1625 Voltage unbalance Enable OFF ON OFF
1626 Voltage unbalance Fail class Warning Shutdown Warning
1985 Ext. run fb. fail
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1986 Ext. run fb. fail Timer 0.0 s 20.0 s - 1.0 s
1987 Ext. run fb. fail Relay output A R0 (none) R26 (relay 26) R0 (none)
1988 Ext. run fb. fail Relay output B R0 (none) R26 (relay 26) R0 (none)
1989 Ext. run fb. fail Enable OFF ON Inhibits OFF
1990 Ext. run fb. fail Fail class Warning Shutdown Warning
2150 Phase sequence error
No. Setting Min. setting Max. setting Third
setting
Factory
setting
2152 Phase seq error Timer 0.0 s 10.0 s - 1.0 s
2153 Phase seq error Relay output A R0 (none) R26 (relay 26) - R0 (none)
2154 Phase seq error Relay output B R0 (none) R26 (relay 26) - R0 (none)
2155 Phase seq error Enable OFF ON Inhibit OFF
2156 Phase seq error Fail class Warning Shutdown - Warning
2160 GB open failure
No. Setting Min. setting Max. setting Factory
setting
2161 GB open failure Timer 0.0 s 10.0 s 1.0 s
2170 GB close failure
No. Setting Min. setting Max. setting Factory
setting
2171 GB close failure Timer 0.0 s 10.0 s 1.0 s
2180 GB position failure
No. Setting Min. setting Max. setting Factory
setting
2181 GB position failure Timer 0.0 s 10.0 s 1.0 s
2182 GB position failure Enable OFF ON ON
2183 GB position failure Fail class Warning Shutdown Warning
2200 MB open failure
No. Setting Min. setting Max. setting Factory
setting
2201 MB open failure Timer 0.0 s 60.0 s 1.0 s
