Deif GC-1F Installation Instructions

GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 16 of 123
It is possible to choose run coil on one relay and stop coil on another, thus supporting engines
with double systems.
The multi-functional inputs can be configured to cover the following functions:
- VDO sensor input
- 0 to 20 mA input
- 4 to 20 mA input
- Binary input with wire break (switch function)
Tacho RPM input (MPU) can be configured to cover the following functions:
- Magnetic pickup (2-wire)
- NPN or PNP pickup*
* These RPM inputs require external equipment.
Tacho RPM input with capacitor (W/L) can be configured to cover the following functions:
- Magnetic pickup (2-wire)
- W terminal on charger alternator
- NPN or PNP pickup*
* These RPM inputs require external components.
The generator voltage and current input can be configured to the following:
- Voltage 100 to 25000 V primary
- Current 5 to 9000 A primary
