Deif GC-1F Installation Instructions

GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 53 of 123
Multi-input 1 Fuel level XXX %
Multi-input 2 Oil press XX.X bar
Multi-input 3 Water Temp XX ˚C
Run hours Run hours XXXXXh
Fire pump hours Fire pump XXXXXh Counting when running feedback
OK and shutdown override input is
active
Battery Battery XX.XV
RPM RPM XXXX
Time and date 10/01 2008 hh:mm:ss
Service 1 Service 1 0 d 0 h
Service 2 Service 2 41 d 16 h
Empty line To make a view nice
EIC speed RPM
EIC T. Coolant EIC T. Coolant
EIC L. Coolant EIC L. Coolant
EIC P. Coolant EIC P. Coolant
EIC T. Oil EIC T. Oil
EIC L. Oil EIC L. Oil
EIC P. Oil EIC P. Oil
EIC T. Fuel EIC T. Fuel
EIC P. Fuel EIC P. Fuel
EIC T. Air Inl. EIC T. Air Inl.
EIC P. Air Inl. EIC P. Air Inl.
EIC P. Boost EIC P. Boost
EIC Faults EIC Faults
EIC Fuel Rate EIC Fuel Rate
EIC P. Charge Air EIC P. Charge Air
EIC T. Charge Air EIC T. Charge Air
EIC DDETorque EIC DDETorque
EIC ACTorque EIC ACTorque
EIC PosAcc EIC PosAcc
EIC Load speed EIC Load speed
EIC T. Ex. Gas EIC T. Ex. Gas
EIC engine run hours EIC engine run hours
EIC P. Fi. Oil EIC P. Fi. Oil
EIC Battery EIC Battery
EIC P. Crank EIC P. Crank
EIC Water In Fuel EIC Water In Fuel
EIC Blowby Flow EIC Blowby Flow
EIC P. Fuel R. EIC P. Fuel R.
EIC P. Timing EIC P. Timing
EIC T. Afterc. W. EIC T. Afterc. W.
EIC T. Turbo Oil EIC T. Turbo Oil
EIC P. Trap Inlet EIC P. Trap Inlet
EIC P. Air in diff EIC P. Air in diff
EIC P. Cool diff EIC P. Cool diff
EIC P. Barometric EIC P. Barometric
EIC T. Ambient Air EIC T. Ambient Air
EIC T. Exh. Right EIC T. Exh. Right
EIC T. Exh. Left EIC T. Exh. Left
EIC T. Winding 1 EIC T. Winding 1
EIC T. Winding 2 EIC T. Winding 2
EIC T. Winding 3 EIC T. Winding 3
EIC P. Aux 1 EIC P. Aux 1
EIC P. Aux 2 EIC P. Aux 2
EIC T. Turbo EIC T. Turbo
EIC T. Intercooler EIC T. Intercooler
