Delem
V0505, 2.19
• Function- and control keys summary
Col.prot.on Collision and backgauge checks on or off
Punch: 1 Punch number selected
die: 1 Die number selected
R-in = 1.3 Inner radius of the bend to be obtained with selected die
Variants On Variants programming enabled: the product has a valid CNC pro-
gram that can be modified from the graphical menu.
Function keys:
unbend/
next
To unbend the graphical product
bend/pre-
vious
To bend the graphical product
shift gauge Select backgauge position
swap Front to back turn of the product.
protection
on/off
To switch the collision detection with collision warning
On or Off.
store Automatic computation of all axes positions (complete
CNC program) and storage in the product library of the
postprocessed product.
MORE>> The softkeys for this mode are divided in two rows. Press
this key to switch from one row to another.
end To go back to the drawing.
