Delem DA-56 - Parameter Explanation

Delem
V0505, 8.3
• Parameter Explanation
Punch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .UP
Number of selected punch in the library.
Press the key to select the required setting.
Die . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .UN
Number of selected die in the library.
Press the key to select the required setting.
Mat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .MA
Selection of one of the programmed materials, which are used to calculate the bending
depths. The control contains 4 preprogrammed materials. In total, 99 materials can be
programmed on the control. See the chapter about programming constants how to pro-
gram materials.
Press the key to select the required setting.
Thickness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TH
Thickness of the plate in millimeters.
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BL
Length of the plate between the tools in millimeters.
Method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BM
Select the required bending method. The control supports 4 methods:
Air bend
Bottoming
Flattening
Flattening & bottoming
Press the key to select the required setting. See chapter 3 for more information about
possible bend methods.
Corr. α . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cα
Correction on angle to bend
The angle correction should be entered as follows:
- Programmed value of 90 degrees.
- Measured value of 92 degrees.
Then it is required to program Corr._ with -2.
- Programmed value of 90 degrees.
- Measured value of 88 degrees.
Then it is required to program Corr._ with +2.
Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .α
Angle to bend
Y-axis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Y
The programmed or calculated Y-axis value to realise a certain angle.
