V0505, 3.10
ters active).
1 = Step change at muting position when the beam moves in opening direction.
2 = Step change at upper dead point.
3 = Step change at upper dead point without movement of any axis and the control goes
to "stop".
4 = Step change if C-input signal becomes active, without movement of the beam. When
you still have a beam movement there will be no retract function of the backgauge per-
formed. See also code 5.
5 = Step change if C-input signal becomes active and the beam is in the upper dead point.
Now you may move the beam and the retract function of the backgauge will be per-
formed.
10= Step change at end of decompression with the Y-axis beam waiting at the pinching
point until the backgauge is at the retract position.
11= Step change at mute position when the beam moves in the opening direction, with
the Y-axis beam waiting at the pinching point until the backgauge is at the retract posi-
tion.
12= Step change at upper dead point, with the Y-axis beam waiting at the pinching point
until the backgauge is at the retract position.
13= Step change at upper dead point without movement of any axis. The Y-axis beam
will wait at the sheet clamp point until the backgauge is at the retract position. After the
bending with this code, the control goes to "stop".
15= Step change if C-input signal becomes active and the beam is in the upper dead
point. The beam may be moved but not necessarily. The Y-axis beam will wait at the
sheet clamp point until the backgauge is at the retract position.
The not mentioned CX-values have no meaning.
Delay time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TX
Programmable delay time before step change (0-30sec)
• Parameter explication (second page)
Auxiliary functions of the bending can be programmed on this page.
