V0505, 5.2
• Edit punch drawing
The display starts prompting the initial dimensions of your punch in the case of programming a
new punch (toolheight, tool angle.).
Hereafter you can enter angle and length dimensions as in the product drawing facilities.
Function keys:
previous
page
To select a previous page within the several pages of the
punch library.
next page To select the next page within the several pages of the
punch library
backup Save tools from library to disk.
restore Load tools from disk into the control.
delete tool Remove tool from library.
edit tool To edit the tool drawing or edit the punch data.
