2
Turn the
computer upside-down, loosen
the
captive screw on
the
memory module cover, and
then
remove
the cover.
1
2
1
captive
screw
2
memory module
cover
NOTICE:
To
prevent damage to the memory module connector, do not use tools to spread the
memory-
module
securing
clips.
3
If
you are replacing a memory module, remove
the
existing
module:
a
Use your fingertips
to
carefully spread apart the securing clips on each end
of
the memory
module
connector
until the
module pops
up.
b
Remove
the
module
from the connector.
Adding and Replacing Parts
117
