128
Dell™ Printer Configuration Web Tool
SSL/TLS
Purpose:
To specify the settings for the SSL encryption communication to the printer, and set/delete the certificate used for
IPsec, or Wireless LAN.
Va lu e s:
HTTP-SSL/TLS
Communication
*1
Select the check box to enable the HTTP-SSL/TLS Communication.
HTTP-SSL/TLS
Communication Port
Number
Sets the port number, which is not identical with that of HTTP for SSL/TLS. This must be 443 or
between 8000 and 9999.
SMTP-SSL/TLS
Communication
Sets the type of SSL/TLS used to communicate with the SMTP server.
Machine Digital
Certificate
Generate Self-Signed
Certificate
*2
Click to display the Generate Self-Signed Certificate page and to create a
security certification from the page. The Generate Self-Signed Certificate
button is available only when the self-signed certificate is not generated.
Certificate Signing
Request (CSR)
*2
Click to display the Certificate Signing Request (CSR) page and to create
a certificate signing request from the page.
Upload Signed
Certificate
*2
Click to display the Upload Signed Certificate page and to upload the
certificate file to the device from the page.
Certificate
Management
*2
Click to display the Certificate Management page and to manage a security
certification from the page.
Delete All Certificates Click to delete all the certificates.
Generate Self-Signed
Certificate
Public Key Method Select the public key method of the self-signed certificate.
Size of Public Key Select the size of public key.
Issuer Enter the issuer of SSL self-signed certificate.
Validity Enter the valid days from 1 to 9999 days.
Generate Signed
Certificate
Click to generate the SSL self-signed certificate.
Certificate Signing
Request (CSR)
Digital Signature
Algorithm
Select the digital signature algorithm.
Public Key Size Select the public key size.
2 Letter Country Code
(Required)
Enter the 2-letter country code.
State / Province Name Enter the state or province name up to 16 bytes.
Locality Name Enter the locality name up to 32 bytes.
Organization Name
(Required)
Enter the organization name up to 32 bytes.
Organization Unit
(Required)
Enter the organization unit up to 32 bytes.
Common Name Display the common name.
E-mail Address Enter the e-mail address.
Upload Signed
Certificate
*2
Password Enter the password to upload the certificate file.
Re-enter Password Enter the password again for confirmation.
File Name Click Browse to browse the file name to upload to the device.

Table of Contents

Other manuals for Dell S2810dn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell S2810dn and is the answer not in the manual?

Dell S2810dn Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeManual
Time to first page (black, normal)7 s
Print speed (black, normal quality, A4/US Letter)35 ppm
Duplex print speed (black, normal quality, A4/US Letter)22 ppm
Printing colorsBlack
Maximum duty cycle40000 pages per month
Recommended duty cycle500 - 3000 pages per month
Number of print cartridges1
Page description languagesPCL 5e, PCL 6, PDF 1.7, PostScript 3, XML
Total input capacity250 sheets
Total output capacity150 sheets
Maximum input capacity350 sheets
Envelopes sizesC5, DL, Monarch
Maximum print size216 x 356 mm
Paper tray media typesPlain paper, Pre-Printed, Recycled paper, Thick paper
Paper tray media weight60 - 80 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Wi-Fi-
Security algorithms802.1x RADIUS, EAP-MD5, EAP-PEAP, HTTPS
Mobile printing technologiesApple AirPrint, Dell Mobile Print, Google Cloud Print
Supported network protocols (IPv4)HTTP, TCP, UDP, ICMP/IGMP, BOOTP, DHCP, RARP, Auto IP, WINS, DNS, Bonjour(mDNS), Telnet
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Memory typeDDR3
Maximum internal memory- MB
Sound power level (standby)24.7 dB
Sound pressure level (printing)53.4 dB
DisplayLCD
CertificationCE, FCC
Display number of lines4 lines
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)45 W
Power consumption (printing)560 W
Mac operating systems supportedMac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supportedWindows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows RT, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Storage temperature (T-T)0 - 35 °C
Operating temperature (T-T)10 - 32 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)15 - 85 %
Package depth545 mm
Package width528 mm
Package height414 mm
Package weight14600 g
Weight and Dimensions IconWeight and Dimensions
Depth438 mm
Width410 mm
Height273 mm
