Maintaining Your Printer
3
Slightly pressing down the lock lever on tray1 to the right with one hand, raise the retard roller with the other hand.
4
Slide the retard roller to the left to remove it from tray1.
Installing a Retard Roller in Tray1
1
Unpack a new retard roller.
2
Hold the both ends of the new retard roller, and attach it by sliding the two axles of the retard roller into the holes
on tray1.
NOTE:
Be careful not to touch the rubber rollers.
