Dell S2810dn User Manual

Setting the IP Address 63
10 Use the number pad to enter the first octet of the IP address, and then Press the button.
The cursor moves to the next digit.
NOTE: You can only enter one octet at a time and must press the button after entering each octet.
11 Enter the rest of the octets, and then press the (Set) button.
NOTE: If the message This Setting Becomes Effective after Restart is displayed, press the
( Back ) button.
12 Press the (Back) button.
13 Press the button until Subnet Mask is highlighted, and then press the (Set) button.
14 Repeat steps 10 and 11 to set Subnet Mask.
NOTE: If the message This Setting Becomes Effective after Restart is displayed, press the
( Back ) button.
15 Press the (Back) button.
16 Press the button until Gateway Address is highlighted, and then press the (Set) button.
17 Repeat steps 10 to 12 to set the Gateway Address.
18 Turn off the printer and then turn it on again.
When Using the Tool Box
1 Click Start  All Programs  Dell Printers  Dell Smart Printer - S2810dn  Tool Box .
The
Tool Box opens.
2 Click the Printer Maintenance tab.
3 Select TCP/IP Settings from the list at the left side of the page.
The
TCP/IP Settings page appears.
4 Select the mode from IP Address Mode , and then enter the values in IP Address, Subnet Mask, and Gateway
Address.
5 Click Apply New Settings to take effect.
You can also assign the IP address to the printer when installing the printer drivers with the installer. When you use the
Wireless or Ethernet Connection feature, and the Get IP Address is set to AutoIP or DHCP on the printer, you
can set the IP address from 0.0.0.0 to the desired IP address on the printer selection window.

Dell S2810dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Manual
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22 ppm
Printing colors	Black
Maximum duty cycle	40000 pages per month
Recommended duty cycle	500 - 3000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF 1.7, PostScript 3, XML
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	350 sheets
Envelopes sizes	C5, DL, Monarch
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Pre-Printed, Recycled paper, Thick paper
Paper tray media weight	60 - 80 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Wi-Fi	-
Security algorithms	802.1x RADIUS, EAP-MD5, EAP-PEAP, HTTPS
Mobile printing technologies	Apple AirPrint, Dell Mobile Print, Google Cloud Print
Supported network protocols (IPv4)	HTTP, TCP, UDP, ICMP/IGMP, BOOTP, DHCP, RARP, Auto IP, WINS, DNS, Bonjour(mDNS), Telnet
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Memory type	DDR3
Maximum internal memory	- MB
Sound power level (standby)	24.7 dB
Sound pressure level (printing)	53.4 dB
Display	LCD
Certification	CE, FCC
Display number of lines	4 lines
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	45 W
Power consumption (printing)	560 W
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows RT, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	15 - 85 %
Package depth	545 mm
Package width	528 mm
Package height	414 mm
Package weight	14600 g

Weight and Dimensions

Depth	438 mm
Width	410 mm
Height	273 mm
