Maintaining Your Printer
255
4
Make sure that the arrow marks on the Transfer Unit and the printer face each other, and then press the two tabs
on Transfer Unit inward to lock.
5
Close the rear cover.
Removing the Retard Roller in Tray1
1
Pull tray1 out of the printer about 200 mm.
2
Hold tray1 with both hands, and remove it from the printer.
NOTE:
Be sure to remove all the paper from tray1 before removing the retard roller.
To Next Page
