150
Understanding the Printer Menus
IP Filter
NOTE:
IP Filter feature is available only for
LPD
or
Port9100
.
Purpose:
To block data received from certain IP addresses through the wired or wireless network. You can set up to five IP
addresses. The change becomes effective after the printer is turned off and then on again.
Va lu e s:
IEEE 802.1x
NOTE:
IEEE 802.1x feature is available only when the printer is connected using LAN cable and it is available only when the IEEE
802.1x authentication is enabled.
Purpose:
To disable IEEE 802.1x authentication. The change becomes effective after the printer is turned off and then on
again.
Reset LAN
Purpose:
To initialize wired network data stored in non-volatile memory (NVM). After executing this function and rebooting
the printer, all wired network settings are reset to their default values.
Delete All Certificates
Purpose:
To delete all certificates of the printer. After executing this function and rebooting the printer, all certificates are
deleted.
PS Data Format
Purpose:
To specify PostScript3 Compatible communication protocol, you can configure the PS Data Format settings.
The change becomes effective after the printer is turned off and then on again.
Va lu e s:
Google Cloud Print Disable Disables Google Cloud Print.
Enable
*
Enables Google Cloud Print.
*1
HTTP-SSL/TLS feature is available only when a digital certificate is set from the Dell Printer Configuration Web Tool.
No. n / IP Address (n is 1–5.) Sets the IP address for Filter
n
.
No. n / Mask (n is 1–5.) Sets the address mask for Filter
n
.
No. n / Mode (n is 1–5.) Off
*
Disables the IP Filter feature for Filter
n
.
Accept Accepts an access from the specified IP address.
Reject Rejects an access from the specified IP address.
Auto Used when auto-detecting the PostScript3 Compatible communication protocol.
Standard Used when the communication protocol is in ASCII interface.
BCP Used when the communication protocol is in binary format.
To Next Page
