Dell S2810dn User Manual

Installing Printer Drivers on Windows
®
Computers 71
Windows
®
7, Windows
®
7 64-bit Edition, or Windows Server
®
2008 R2
1
Extract the following zip file to your desired location.
D:\Drivers\XPS\Win_7Vista\XPS-V3_S2810dn.zip (where D is the drive letter of the optical drive)
2 Click Start  Devices and Printers .
3 Click Add a printer .
When you use Windows Server
®
2008 R2, click Add a local or network printer as an administrator .
If the
User Account Control dialog box appears, click Yes .
NOTE: If you are an administrator on the computer, click Yes; otherwise, contact your administrator to continue the desired
action.
4 Click Add a local printer .
5 Select the port connected to this product, and then click Next .
6 Click Have Disk to display the Install From Disk dialog box.
7 Click Browse , and then select the extracted folder in step 1.
8 Click OK .
9 Select your printer name and click Next .
10 To change the printer name, enter the printer name in the Printer name box, and then click Next .
To use this printer as the default printer, select the
Set as the default printer check box, and then click Next .
11 If you do not share your printer, select Do not share this printer . If you share your printer, select Share this printer
so that others on your network can find and use it
.
12 Click Next .
Installation starts.
13 As the driver installation is completed, click Print a test page to verify installation.
14 Click Finish .
Windows
®
8, Windows
®
8 64-bit Edition, Windows
®
8.1, Windows
®
8.1 64-bit Edition, Windows Server
®
2012,
or Windows Server
®
2012 R2
1
Extract the zip file you downloaded to your desired location.
D:\Drivers\XPS\Win_8\XPS-V4_S2810dn.zip (where D is the drive letter of the optical drive)
2 On the Desktop screen, right-click the bottom left corner of the screen, and then click Control Panel .
3 Click Hardware and Sound ( Hardware for Windows Server
®
2012/Windows Server
®
2012 R2)  Devices and
Printers
 Add a printer .
4 Click The printer that I want isn’t listed .
5 Select Add a local printer or network printer with manual settings , and then click Next .
6 Select the port connected to your printer, and then click Next .
7 Click Have Disk to display the Install From Disk dialog box.
8 Click Browse , and then select the extracted folder in step 1.
9 Click OK .
10 Select your printer name and click Next .
11 To change the printer name, enter the printer name in the Printer name box, and then click Next . Installation
starts.

Dell S2810dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Manual
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22 ppm
Printing colors	Black
Maximum duty cycle	40000 pages per month
Recommended duty cycle	500 - 3000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF 1.7, PostScript 3, XML
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	350 sheets
Envelopes sizes	C5, DL, Monarch
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Pre-Printed, Recycled paper, Thick paper
Paper tray media weight	60 - 80 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Wi-Fi	-
Security algorithms	802.1x RADIUS, EAP-MD5, EAP-PEAP, HTTPS
Mobile printing technologies	Apple AirPrint, Dell Mobile Print, Google Cloud Print
Supported network protocols (IPv4)	HTTP, TCP, UDP, ICMP/IGMP, BOOTP, DHCP, RARP, Auto IP, WINS, DNS, Bonjour(mDNS), Telnet
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Memory type	DDR3
Maximum internal memory	- MB
Sound power level (standby)	24.7 dB
Sound pressure level (printing)	53.4 dB
Display	LCD
Certification	CE, FCC
Display number of lines	4 lines
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	45 W
Power consumption (printing)	560 W
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows RT, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	15 - 85 %
Package depth	545 mm
Package width	528 mm
Package height	414 mm
Package weight	14600 g

Weight and Dimensions

Depth	438 mm
Width	410 mm
Height	273 mm
