 Precautions for Correct Use

The input variables are not allowed to omit. An error will occur during the compiling of the software if
any input variable is omitted. But the output variable is allowed to omit.

The data type of output variables must be BOOL. Otherwise, an error will occur during the compiling
of the software.

Programming Example

The data types of EQ_In1, EQ_In2 and EQ_In3 are INT, UINT and DINT respectively and the
data type of Out1 is BOOL.
Out1 changes to TRUE when the values of EQ_In1, EQ_In2 and EQ_In3 are 50, 50 and 50
respectively and EQ_EN changes to TRUE as shown in Variable 1.
Out1 changes to FALSE when the values of EQ_In1, EQ_In2 and EQ_In3 are 10, 50 and 100
respectively and EQ_EN changes to TRUE as shown in Variable 2.
 Variable 1
Variable name
Data type
Current value
EQ_EN
BOOL
TRUE
EQ _In1
INT
50
EQ _In2
UINT
50
EQ _In3
DINT
50
Out1
BOOL
TRUE
 Variable 2
Variable name
Data type
Current value
EQ_EN
BOOL
TRUE
EQ _In1
INT
10
EQ _In2
UINT
50
EQ _In3
DINT
100
Out1
BOOL
FALSE
 The Program

The data types of EQ_In1 and EQ_In2 are both TIME and the data type of Out1 is BOOL.
Out1 changes to TRUE when the values of EQ_In1 and EQ_In2 are T#50ms and T#50ms
respectively and EQ_EN changes to TRUE.
 The variable table and program
Variable name Data type Current value
EQ_EN
BOOL
TRUE
EQ _In1
TIME
T#50ms
EQ _In2
TIME
T#50ms
Out1
BOOL
TRUE
1
EQ
EN ENO
In1 Out
In3
In2
EQ_EN
EQ_In 1
EQ_In 3
EQ_In 2
Out1
1
EQ
EN ENO
In1 Out
In2
EQ_EN
EQ_In1
EQ_In2
Out1
