Chapter 8 Logic Instructions
8_
Data type
The value of In corresponds to the value of Out
In
Out
In
Out
UDINT
BYTE
16#****_**00~16#****_**FF
16#00~16#FF
WORD
16#****_0000~16#****_FFFF
16#0000~16#FFFF
DWORD
16#0000_0000~16#FFFF_FFFF
16#0000_0000~16#FFFF_FFFF
LWORD
16#0000_0000~16#FFFF_FFFF
16#0000_0000_0000_0000~
16#0000_0000_FFFF_FFFF
ULINT
BYTE
16#****_****_****_**00~
16#****_****_****_**FF
16#00~16#FF
WORD
16#****_****_****_0000~
16#****_****_****_FFFF
16#0000~16#FFFF
DWORD
16#****_****_0000_0000~
16#****_****_FFFF_FFFF
16#0000_0000~16#FFFF_FFFF
LWORD
16#0000_0000_0000_0000~
16#FFFF_FFFF_FFFF_FFFF
16#0000_0000_0000_0000~
16#FFFF_FFFF_FFFF_FFFF
SINT
BYTE
16#00~16#FF
16#00~16#FF
WORD
16#00~16#FF
16#0000~16#00FF
DWORD
16#00~16#FF
16#0000_0000~16#0000_00FF
LWORD
16#00~16#FF
16#0000_0000_0000_0000~
16#0000_0000_0000_00FF
INT
BYTE
16#**00~16#**FF
16#00~16#FF
WORD
16#0000~16#FFFF
16#0000~16#FFFF
DWORD
16#0000~16#FFFF
16#0000_0000~16#0000_FFFF
LWORD
16#0000~16#FFFF
16#0000_0000_0000_0000~
16#0000_0000_0000_FFFF
DINT
BYTE
16#****_**00~16#****_**FF
16#00~16#FF
WORD
16#****_0000~16#****_FFFF
16#0000~16#FFFF
DWORD
16#0000_0000~16#FFFF_FFFF
16#0000_0000~16#FFFF_FFFF
LWORD
16#0000_0000~16#FFFF_FFFF
16#0000_0000_0000_0000~
16#0000_0000_FFFF_FFFF
LINT
BYTE
16#****_****_****_**00~
16#****_****_****_**FF
16#00~16#FF
WORD
16#****_****_****_0000~
16#****_****_****_FFFF
16#0000~16#FFFF
DWORD
16#****_****_0000_0000~
16#****_****_FFFF_FFFF
16#0000_0000~16#FFFF_FFFF
LWORD
16#0000_0000_0000_0000~
16#FFFF_FFFF_FFFF_FFFF
16#0000_0000_0000_0000~
16#FFFF_FFFF_FFFF_FFFF

Integer to Integer
 The Integer data can be converted to the Integer data. And some instructions are shown below.
SINT_TO_INT
EN ENO
Out
In
INT_TO_SINT
EN ENO
Out
In
USINT_TO_DINT
EN ENO
OutIn
UINT_TO_ULINT
EN ENO
OutIn
8-161
