ASDA-A2 Chapter 1 Inspection and Model Explanation
1-2 Revision February, 2017
(10) Servo drive power input:
220V:
Control circuit power Main circuit power
100 W ~ 3 kW
L1c, L2C, fast connector
R, S, T fast connector
405 kW ~ 15 kW
L1c, L2C, terminal block
R, S, T terminal block
400V:
Control circuit power Main circuit power
750 W ~ 1.5 kW
DC24V, DC0V, fast connector
R, S, T fast connector
2 kW ~ 7.5 kW
DC24V, DC0V, terminal block
R, S, T terminal block
(11) 3-PIN fast connector (U, V, W)
(12) 3-PIN fast connector (P , D, C)
(13) A plastic lever (for 220V 100 W ~ 3 kW and 400V 750 W ~ 1.5 kW)
(14) A metal short-circuit chip (for 220 V 100 W ~ 4.5 kW and 400 V 750 W ~ 1.5 kW)
(15) An installation manual
