ASDA-A2 Chapter 3 Wiring
Revision February, 2017 3-11
ECMA-F
△
1830S (3000W)
ECMA-E
△
1835S (3500W)
ECMA-F
△
1845S (4500W)
ECMA-F
△
18553 (5500W)
ECMA-F
△
18753 (7500W)
ECMA-F1221B3 (11kW)
ECMA-F1221FS (15kW)
Please select shielded multi-core and the shielded cable should connect to the SHIELD end.
Please refer to the description of Section 3.1.6.
NOTE
1) Box, (
△
) in servo motor model represents encoder type.
△
= 1: incremental,
20-bit;
△
= 2: incremental, 17-bit;
△
= 3: 2500ppr;
△
= A: absolute.
2) Box, () in servo motor model represents brake or keyway / oil seal.
