ASDA-A2 Chapter 3 Wiring
Revision February, 2017 3-15
Installation Notes:
1. Check if the power and wiring among R, S, T and DC24V, DC0V are correct.
Please refer to Chapter 11 for Specifications. Make sure the input voltage is correct, or it might
damage the servo drive or danger may occur.
2. Check if the output terminal U, V, W of the servo motor is correctly wired. The incorrect wiring
may disable the operation of the motor or cause the malfunction.
3. When applying to the external regenerative resistor, the contact between P and D should be
opened and the external regenerative resistor should connect to terminal P and C. When
applying to the internal regenerative resistor, the contact between P and D should be closed
and the contact between P and C should be opened.
4. When an alarm occurs or the system is in emergency stop status, use ALARM or WARN to
output and disconnect the power of magnetic contactor in order to disconnect the power of
servo drive.
