VFD EtherNet/IP Option Card
Option Card Application Manual
51
8. Select Scan Network on the toolbar to select the device to join the network. You can select
multiple devices at one time. If you have any questions about adding devices to the network,
contact your device supplier to get the correct EDS file. For how to import the EDS file, see
following sections.
9. Click the red dot on PLC and the drive figure, and then drag them to the same connection
line. Or, right-click in an empty space, select Fast Connect, select the device, and then add
a new connection.
10. After the connection is established, right-click the red dot on PLC figure to open Data
Mapping. A new page Network_0 automatically opens.
