Delta Ultron HPH series User Manual

7-23
7
LCD Display & Settings
7.10 UPS Settings
7.10.1 Bypass Setting
Path:
SETUP
ĺ%\SDVV6HWWLQJ
After entering the BYPASS SETTING screen (shown in the figure below), the user can
set up the Bypass Frequency Range, Bypass Voltage (Max.), Bypass Voltage (Min.)
and ECO Voltage Range. If the range is exceeded, the system will issue an alarm. Only
TXDOL¿HGVHUYLFHSHUVRQQHOFDQSHUIRUPWKHDERYHPHQWLRQHGVHWXSLWHPV3OHDVHFRQWDFW
Delta customer service for assistance.
Bypass
±
+-
3
10
Hz
%
±
9
%
10
%
UPS-1.1
SETUP MAINTENANCE EVENT LOGLOG IN
Administrator
MEASUREMENT
Bypass setting
BYPASS SETTING
Bypass Frequency Range Bypass Voltage(Max) Bypass Voltage(Min)
ECO Voltage Range(±%)
09:30
May 10,2018
Item Description
Bypass Frequency Range Set up the bypass output’s frequency range.
Bypass Voltage (Max.) Set up the bypass output’s maximum voltage.
Bypass Voltage (Min.) Set up the bypass output’s minimum voltage.
ECO Voltage Range Set up the bypass output’s voltage range in ECO mode.
