Delta Ultron HPH series User Manual

2-4
Ultron HPH Series
No. Item Q'ty
10
6-Pin Dry Contact Terminal Block
(used for MODBUS and BMS ports located at the
rear of the touch panel; please refer to Figure 4-18)
1 PC
11
8-Pin Dry Contact Terminal Block
(used for (1) external battery temperature dry
contacts and (2) external switch/ breaker status
dry contacts; please refer to Figure 4-3)
2 PCS
12
10-Pin Dry Contact Terminal Block (used for input
and output dry contacts; please refer to Figure 4-3)
2 PCS
4. If there is any damage or anything missing, please immediately contact the dealer
from whom you purchased the unit.
5. If the UPS needs to be returned, carefully repack the UPS and all of the accessories
using the original packing material that came with the unit.
2.3 Functions & Features
y
Hot swappable STS module and communication interfaces realize on-line maintenance
and reduce the MTTR (Mean Time to Repair).
y
Input power factor > 0.99 and input THDi < 3% save on installation cost and diminish
power contamination.
y
(ႈFLHQF\!VDYHVRQRSHUDWLRQFRVW
y
Automatic input frequency detection enables operation at 50Hz or 60Hz.
y
Automatic restart:
1. The UPS will restart in normal mode automatically right after the AC line resumes
following a low battery shutdown.
2. The UPS returns automatically to normal mode from bypass mode after an overload
condition is cleared.
y
Automatically detects whether bypass voltage is out of rating voltage (default: voltage
±15% & frequency ±3Hz). If yes, the UPS will stop supplying power to the critical loads
to protect your electronic equipment.
y
Supports ECO mode: when input voltage and frequency are within the range of rating
voltage ±10% and rating frequency ±3Hz, the UPS will transfer to bypass mode; other-
ZLVHWKH836ZLOOWUDQVIHUWRQRUPDOPRGHWRUHDFKKLJKHUHႈFLHQF\
