Denon AVR-4806 - Connecting Other Sources: Recorder Connections; Connecting a DVD Recorder

31
Connecting Other Souces
Connecting a DVD recorder
DVD recorder
S VIDEO
OUT
S VIDEO
IN
R
L
AUDIO IN
R
L
AUDIO OUT
VIDEO
OUT
VIDEO
IN
OPTICAL
IN
OPTICAL
OUT
R
L
R
L
H
H
I
I
A
R
L
R
L
A
D
D
COMPONENT VIDEO OUT
Y
P
B
PR
J
• For best picture quality choose the component video connection to your DVD recorder. S-Video and composite video outputs
are also provided. If you choose to use the component video connection, it needs to be assign. For more information about
Component Input Assignment ( page 97).
• If you wish to perform analog dubbing from a digital sources, such as a DVD recorder to an analog recorder such as a cassette
deck, you will needs connect analog inputs and outputs as shown below, in addition to the digital audio connections.
NOTE:
•When recording to DVD recorder, it is necessary that the type of cable used with the playback source equipment be the
same type that is connected to the AVR-4806 VCR-1 (to 3) OUTPUT terminal.
Example: VCR-1 IN
→ S-Video cable : VCR-1 OUT→ S-Video cable
VCR-1 IN → Video cable : VCR-1 OUT→ Video cable
• Do not connect the output of the component connected to the OPTICAL 2 OUT terminal on the AVR-4806’s rear panel to
any terminal other than the OPTICAL 2 IN terminal.
