64
Basic Operation
Fader function
• This function makes it possible to lower the volume of the
front channels (FL, C and FR) or the rear channels (SL, SR,
SBL and SBR) together. Use it for example to adjust the
balance of the sound from each position when multi-channel
music sources are played.
1
Press the ENTER button.
• Display the “Channel Vol.” screen.
2
Press the CURSOR
DD
,
HH
or ENTER button then
select “Fader”.
The channel switches in the order shown below each
time the ENTER button is pressed.
•You can adjust the channel level either according to the
playback sources or to suit your tastes, as described below.
1
Press the ENTER button.
• Display the “Channel Vol.” screen.
2
Press the CURSOR
DD
,
HH
or ENTER button to
select the speaker.
The channel switches as shown below each time the
ENTER button is pressed.
Channels which is not used are not displayed.
3
Press the CURSOR
FF
or
GG
button to adjust the
level.
The adjustment range for the different channels is +12
dB to –12 dB in step of 0.5 dB.
The sound from the subwoofer can be completely cut
by lowering the SW (subwoofer) setting one additional
from –12 dB (setting it to “OFF”).
• When the surround back speaker setting is set to “1spkr”
for “Speaker Configuration” ( page 113, 114), this is set
to “SB”.
Channel Level
FUNCTION
ENTER
CURSOR
NUMBER /
SYSTEM CALL
TUNER
BAND
TUNING
MODE
ENTER
CURSOR
FUNCTION
SOURCE
To Next Page
