Connecting Other Souces
ZONE2/ZONE3 speaker out connections
• When the power amplifier is assigned to the ZONE2 or ZONE3 output channel at “Power Amp Assign” in the “System Setup
Menu”, the MAIN ZONE speaker terminals can be used as the ZONE2 or ZONE3 speaker out terminals ( page 106, 107).
• The connections diagram below is an example for when the surround back speaker is assigned to the ZONE2 stereo 2 channel.
In this case, Surround Back Speaker OUT can not be used for MAIN ZONE.
>< <>
><
><
>< >< <><>
<>
IN
(
L
)
(
R
)
(
R
) (
R
) (
L
) (
L
)
(
L
)
(
R
)
Connection terminal
for subwoofer with
built-in amplifier
(subwoofer), etc.
Surround
left speaker
(A)
Subwoofer
Front
right speaker
Surround
left speaker (B)
ZONE2 Front
left speaker
Front
left speaker
Center
speaker
ZONE2 Front
right speaker
Surround
right speaker (B)
Surround
right speaker
(A)
ZONE2
