Preparing the Material
28
STEP 5 : Perform the Surface Leveling of the Material
Attach the material using the same procedure as the scrap board, and
perform surface leveling.
Procedure
1. Attach the material to the scrap board.
*Mark the location that will be the origin point of the material.
MEMO
If you mount it in a position in the front, the work will be easier.
Front
2. Set the origin point to suit the material.
"“STEP 3 : Set the Origin Point” (p. 22)
3. Level the material surface.
Level the material surface using the same procedure as when leveling the
scrap board surface.
"“STEP 4 : Level the Scrap Board Surface” (p. 26)
Precautions to Take When Leveling the Material Surface
*Make sure to reset the Z origin point to suit the material.
Failure to perform this operation may result in the cutting tool
hitting the material, which may cause the material to come loose
and damage the cutting tool.
Scrap Board
Table
Material
Scrap Board
Table
Z origin point
〇〇〇〇●〇
To Next Page
