DGSHAPE monoFab SRM-20 - STEP 12: Set the Drilling Process

Creating a MODELA Player 4 File
97
STEP 12 : Set the Drilling Process
Drilling
Several reversal methods can be used to cut both sides accurately in the same position. The procedure described in this section assumes that positioning pins are
used to reverse the cutting material. The procedure involves drilling holes for inserting positioning pins.
Reversal process using positioning pins
材料
捨て板
テーブル
〇〇〇〇〇〇〇〇〇〇〇●〇
