DGSHAPE monoFab SRM-20 - STEP 7: Set the Surface leveling Process of the Scrap Board

Creating a MODELA Player 4 File
74
STEP 7 : Set the Surface leveling Process of the Scrap Board
Surface leveling of Scrap Board
In the case you use a scrap board for double-sided cutting, the rst step is to level the scrap board surface. You have not only to
level the material surface but also level the scrap board surface; this is required to make the top and bottom surfaces of the material
parallel with the cutting plane along which the cutting tool moves. By leveling the surface of the scrap board that will be attached
to the table on the machine, you can create a work plane that is parallel with the cutting plane along which the cutting tool moves.
〇〇〇〇〇〇●〇〇〇〇〇〇
Cutting plane
along which
the cutting
tool moves
Scrap Board
Table
Scrap Board
Table
