Cutting (Double Sided)
112
STEP 3 : Perform the Surface Leveling of the Scrap Board
The points to be checked before cutting
Check the following things before starting cutting. If there are problems
with any of these, the cutting material may be wasted or the machine may
be damaged.
□ Is an output le right?
□ Have you made a mistake with the origin point position?
□ Do the cutting conditions match the type of cutting material?
Procedure
1. Only enable the “Scrap board Surfacing” process on the MODELA
Player 4. (Figure at right)
1-1.
Click the unnecessary process of the cutting process list.
1-2.
Click [Enable/Disable Cutting].
1-3.
Repeat procedures 1-1 and 1-2, and disable the processes that are not
required.
Only the orange processes will be output.
〇〇●〇〇〇〇〇〇〇〇〇
