DGSHAPE monoFab SRM-20 - Table of Contents; Contents

2
Contents
Contents .....................................................2
Preparing the Machine .......................................4
Preparing the Machine ........................................5
Flow Diagram ...........................................5
STEP 1 : Turning the Power On ...........................6
STEP 2 : The Machine Run-in .............................7
STEP 3 : Conrm the Command Set .......................9
STEP 4 : Register the Cutting Tool You Want to Use
(when you are using SRP Player) ........................ 10
STEP 5 : Attach the Cutting Tool ........................ 11
Guide for Cutting with SRP Player ........................... 14
The Flow of Double-Sided Cutting .......................... 15
The Flow of Double-Sided Cutting .....................15
Items Necessary for Cutting ................................. 16
Items to Prepare Yourself ...............................18
Preparing the Material ...................................... 19
STEP 1 : Attach the Material to the Scrap Board ......... 19
STEP 2 : Install the Cutting Tool .........................21
STEP 3 : Set the Origin Point ............................ 22
STEP 4 : Level the Scrap Board Surface .................. 26
STEP 5 : Perform the Surface Leveling of the Material ...28
STEP 6 : Level the Bottom Surface of the Material ....... 30
Creating an SRP Player File .................................. 31
STEP 1 : Measure the Thickness of the Material .......... 31
STEP 2 : Determine the Size and
Orientation of the Model. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
STEP 3 : Determine What to Do ......................... 35
STEP 4 : Create the Cutting Data ........................ 37
STEP 5 : Preview the Result of Cutting .................. 40
Cutting (Double Sided). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
STEP 1 : Set the Origin Point ............................ 41
STEP 2 : Perform the Roughing ......................... 42
STEP 3 : Perform the Finishing .......................... 47
STEP 4 : Set the Drilling Process ........................ 52
STEP 5 : Drill the Scrap Board ........................... 56
STEP 6 : Reverse the Material ........................... 60
STEP 7 : Cut the Bottom Surface ........................ 62
STEP 8 : Remove the Cut Material ....................... 63
STEP 9 : Turning the Power O ......................... 64
Guide for Cutting with MODELA Player 4 .................... 65
The Flow of Double-Sided Cutting .......................... 66
The Flow of One Side Cutting .......................... 66
Items Necessary for Cutting ................................. 67
Items to Prepare Yourself ...............................69
