DGSHAPE monoFab SRM-20 - STEP 9: Set the Surface leveling Process of the Material

Creating a MODELA Player 4 File
83
STEP 9 : Set the Surface leveling Process of the Material
Surface leveling of the Material
Leveling eliminates unevenness in the surface of a material to make it parallel with the cutting plane along which the cutting tool moves. For double-sided cutting,
each of the top and bottom surfaces must be leveled. The leveling cutting depth should be set to a value calculated using the following formula so that the
material is not smaller than the model size:
(Material thickness) - (Model height) > Leveling cutting depth (top surface + bottom surface)
“Perfume.stl“
30mm 27mm
〇〇〇〇〇〇〇〇●〇〇〇〇
Cutting plane
along which
the cutting
tool moves
Material
Scrap Board
Table
Material
Scrap Board
Table
