Creating a MODELA Player 4 File
84
Procedure
1. Create the surface leveling process of material.
Select the top surface, then click [New Process].
2. Set the type of process.
Select [Surfacing], then click [Next].
3. Set the cutting surface.
Check that the surface selected in procedure 1 is selected, and click [Next].
4. Select the cutting tool.
“Perfume.stl”: “3 mm Square” [Next]
To Next Page
