OPERATOR’S MANUAL
GAC® 2100 Grain Analysis Computer (Blue, Gray, Agri Models)
11001-1688-201609
54 INSTRUMENT SETUP
To Configure COM1 or COM2 Format:
(2 or 6 key from the Communications menu):
1. After completing steps 1 through 4 from the basic entry procedure, edit
the configuration. Both the COM1 FORMAT and COM2 FORMAT
selections are similar and therefore are described together. The COM
Format Selection menu displays two lines each containing several
choices (Figure 44).
2. Select the OUTPUT FORMAT using the pointer. Place the pointer in
front of the correct line with the Up/Down Arrow keys.
3. Edit the line by using the Left/Right Arrow keys to cycle through six
variations. Select the appropriate format from the following six choices:
– PRN20 - Standard 20 column printer output.
– PRN80 - Standard 80 column printer output.
– TST20 - 20 column test output of printer parameters.
– PRN81 - Standard 80 column printer output (2 lines).
– CSV01 - Comma separated variables.
– PRN21 - Special 20 column printer output. PRN 20 format with the
Grain Calibration Date Code, Instrument Serial Number and
D-values removed.
4. Select the LINE TERMINATOR with the pointer. An RS-232 line of
input data must be terminated with one of the following characters or
character pairs.
– LF (Line Feed) 0A Hex
– CR (Carriage Return) 0D Hex
– LF + CR 0A, 0D Hex
– CR + LF 0D, 0A Hex
5. After editing is complete, select the Previous Page key to return to the
Communications menu for the next selection.
Up/Down Arrow Keys
