Ext Stereo In (Ext St 1 + St 2)
External Stereo Inputs Connect external stereo
sources (such as a DAT or CD player) to the Ex-
ternal Stereo Inputs.
Monitor Section Outputs
C|24 Monitor section outputs appear on two
DB-25 female connectors on the back panel, la-
beled as follows:
• Control Room Out (5.1 Mon Out L:1 R:3)
• Cue Outputs (Cue + SLS + TB)
The Monitor section output mode can be set to
5.1, LCRS, or Stereo using the Monitor mode
switches on the top panel of C|24.
Monitor section output connections are shown
in the following tables.
Control Room Out (5.1 Mon Out L:1 R:3)
Main Outputs Connect the Main Outputs to
your primary studio monitors (tables are shown
below for 5.1, LCRS and Stereo Main monitor
setups).
Alternate Outputs Connect the Alternate Out-
puts to a secondary pair of studio monitors. The
Alt Outputs (L-R) are also available on 1/4-inch
balanced TRS connectors on the back panel, and
mirror the output signal on the Alt Outputs on
the Control Room Out connector.
Main Outputs (5.1) and Alternate Outputs
Ext Stereo In (Ext St 1 + St 2)
Channel Signal
1 Ext Stereo 1 In Left
2 Ext Stereo 1 In Right
3 Ext Stereo 2 In Left
4 Ext Stereo 2 In Right
5 (Unused)
6 (Unused)
7 (Unused)
8 (Unused)
Control Room Out (5.1 Mon Out L:1 R:3)
Channel Signal
1 Main Output Left (L)
2 Main Output Center (C)
3 Main Output Right (R)
4 Main Output Left Surround (Ls)
5 Main Output Right Surround (Rs)
6 Main Output LFE (LFE)
7 Alt (Stereo) Output Left
8 Alt (Stereo) Output Right

DigiDesign C24 Specifications

General

Type	Control Surface
Channels	24
Compatibility	Pro Tools
Faders	24 motorized
Inputs	8 analog line inputs
Outputs	8 analog line outputs
Aux Sends	N/A (Control surface only)
Connectivity	Ethernet, MIDI
Display	LCD scribble strips
Power Supply	External power supply
