DigiDesign C24 User Manual

Chapter 4: Audio Connections 25
Main Outputs (LCRS) and Alternate Outputs
Main Outputs (Stereo) and Alternate Outputs
Alternate Outputs (Stereo)
Cue Outputs (Cue + SLS +TB)
Cue Outputs Connect the Cue Outputs to the in-
puts of your cue system.
Studio LS Outputs Connect Studio LS Outputs to
speakers in your live room.
Talkback Slate Output Connect the Talkback
Slate Output to an available Pro Tools input to
record slate information.
Control Room Out (5.1 Mon Out)
Channel Signal
1 Main Output Left (L)
2 Main Output Center (C)
3 Main Output Right (R)
4 Surround Output (S)
5 (Unused)
6 (Unused)
7 Alt (Stereo) Output Left
8 Alt (Stereo) Output Right
Control Room Out (5.1 Mon Out)
Channel Signal
1 Main Output Left (L)
2 (Unused)
3 Main Output Right (R)
4 (Unused)
5 (Unused)
6 (Unused)
7 Alt (Stereo) Output Left
8 Alt (Stereo) Output Right
Alt Outputs (Alt Out L-R on 1/4-inch TRS connectors)
Chan Signal
1 Alt (Stereo) Output Left
2 Alt (Stereo) Output Right
Cue Outputs (Cue + SLS + TB)
Channel Signal
1 Cue Out Left
2Cue Out Right
3 Studio LS Out Left
4 Studio LS Out Right
5 Talkback Slate Out
6 (Unused)
7 (Unused)
8 (Unused)

DigiDesign C24 Specifications

General

Type	Control Surface
Channels	24
Compatibility	Pro Tools
Faders	24 motorized
Inputs	8 analog line inputs
Outputs	8 analog line outputs
Aux Sends	N/A (Control surface only)
Connectivity	Ethernet, MIDI
Display	LCD scribble strips
Power Supply	External power supply
