Page #53 background imageLoading...
Page #53 background image
Digital Projection E-Vision 7000 Series Menu Map Operating Guide
Page 47
Rev B May 2013
INSTALLATION
Language Select from list
Lamp Control Both, Lamp 1, Lamp 2, Auto 1
Lamp Mode Normal, Eco
Projection Mode Front, Rear, Ceiling and Rear, Front and Rear
Fan Mode Normal, High
Test Pattern None, RGB Ramps, Color Bars, Step Bars, Checkboard, Grid, Horizontal Lines, Vertical Lines,
Diagonal lines, Horizontal Ramp, Vertical Ramp, White
Advance Setting
Keystone
Image Resizing
Filter Message 100H, 200H, 500H, Off
LAN/RS232C LAN, RS232C
Network Link, DHP Client On/Off, IP Address, Subnet Mask, Gateway, DNS
Communication Speed 38,400, 19,200, 9,600
Apply Projectorwillaskforconrmationbeforeapplyingtheabovechanges
Reset
All Reset Projectorwillaskforconrmationbeforerestoringallsettingstofactorydefaults
Filter Timer Reset Projectorwillaskforconrmationbeforeresettingthetimertozero
Information Input, Signal Info, Lamp 1 Timer, Lamp 2 Timer, Filter Timer, Model Name, Software Version
Menu Submenus and controls
Notes
Some of the information in this menu
map is summarised. See the actual
menu on the projector for full detail.
Some menu options and controls
may not be available due to settings
in other menus. These will be
shaded grey on the actual menu.
Where it would be helpful, some
menu options are described in more
detail earlier in this operating guide.
