Digital Projection Titan Quad / 800 / 930 Series POSITIONING THE IMAGE Reference Guide
130
Rev H October 2013
Positioning The Image
The normal position for the projector is at the centre of the screen. However, you can set the projector above or below the centre, or to one
side, and adjust the image using the Lens shift feature (known as rising and falling front) to maintain a geometrically correct image.
Notes
For more information on shifting
the lens, see Lens menu in the
Operating Guide.
Whenever possible, position the
projector so that the lens is centered
for the highest quality image.
Shifting the lens up (rising front)
Centered lens
Shifting the lens down (falling front)
Notes
