Digital Projection Titan Quad / 930 / 800 Series USING THE PROJECTOR Operating Guide
50
Rev H October 2013
Size & Position
• Set Enable to On or Off.
• Use Setting to choose:
Global, in which case these settings will be applied to all signals on all inputs.
or Per Mode, in which case these settings will be applied only to the current input signal.
• Set the H Position and V Position sliders as required.
• Set H Size and V Size. When Aspect Lock is set to On, the V Size slider is disabled.
• Select Reset and press OK to reset all the sliders.
Blanking
Blanking curtains can be applied to each edge of the projected image.
• Set Enable to On or Off.
• Set the sliders as required.
Notes
Main Menu
Geometry
Size & Position
Main Menu
Geometry
Blanking
