Digital Projection Titan Quad / 930 / 800 Series SIGNAL INPUTS AND OUTPUTS Connection Guide

Rev H October 2013

DVI input connection example

Notes

Dual link DVI:

high bandwidth/frame rate

Single or Dual link DVI video source

Input 9

Single link DVI video source

Input 3

Input 10

Single link DVI or HDMI video source

Dual Pipe 3D video source

Input 11: Input 9 MAIN and Input 10 SUB
