Digital Projection Titan Quad / 800 / 930 Series APPENDIX B: LENS CHARTS Reference Guide
151
Rev H October 2013
SX+ (1400 x 1050 pixels)
Full width images - the same chart
Formats that t the width of the DMD™ without applying a throw ratio correction (TRC) include:
• 2.35:1 (Scope) 1400 x 596 pixels TRC = 1
• 1.85:1 (Flat) 1400 x 757 pixels TRC = 1
• 1.78:1 (16:9) 1400 x 786 pixels TRC = 1
• 1.66:1 (Vista) 1400 x 843 pixels TRC = 1
• 1.6:1 (16:10) 1400 x 875 pixels TRC = 1
• 1.33:1 (4:3) 1400 x 1050 pixels (native resolution) TRC = 1
Full height images - different charts
A throw ratio correction (TRC) has been applied to the following chart:
1.25:1 (5:4) 1312 x 1050 pixels TRC = 1.07
Notes
For information about individual lens
part numbers, see Appendix A:
Lens Part Numbers.
