Digital Projection Titan Quad / 800 / 930 Series ASPECT RATIOS EXPLAINED Reference Guide

136

Rev H October 2013

Aspect ratio examples for DMD™ resolution SX+ (SXGA+) (continued)

Source: 16:10

Unused screen areas

Cropped parts of the image

Aspect Ratio: Fill & Crop

Aspect Ratio: Fill Display

Aspect Ratio: Source

2 2

Notes
